GoodWe 5kw Battery Lynx A G3 Series (LV) - LX A5.0-30 ( 5kWh )

GoodWe's Lynx A G3 Series is a reliable low-voltage LFP battery designed for residential energy storage. It helps optimize solar self-consumption and provides dependable backup power. Featuring high energy density, a built-in Battery Management System, and support for up to 30 units in parallel, it’s a compact, scalable solution with long cycle life—perfect for lasting home energy efficiency.

Detailed Technical Specifications

Specification Category	Parameter	Numerical Value / Detail
Energy & Capacity	Nominal Battery Energy	5.12 kWh
	Usable Battery Energy	5.0 kWh (at 90%–100% DoD testing baseline)
	Nominal Capacity	100 Ah
	Round-Trip Efficiency	$\ge$ 96.0%
	Cycle Life	> 6,000 cycles (at 90% DoD, 70% EOL)
Electrical Parameters	Nominal System Voltage	51.2 V
	Operating Voltage Range	43.20 V – 58.24 V
	Nominal Charge Current	60 A
	Max Continuous Charge Current	90 A
	Nominal Discharge Current	100 A
	Max Continuous Discharge Current	150 A (approx. 1.5C capability)
	Peak / Pulse Discharge Current	< 200 A (for 30 seconds)
	Max Continuous Discharge Power	7,200 W (7.2 kW)
System Scalability	Maximum Parallel Connections	Up to 30 units
	Maximum Scaled System Energy	Up to 153.6 kWh nominal (150 kWh usable)
	Parallel Connection Architecture	Hand-to-hand / Combiner box / Busbar
Mechanical Dimensions	Dimensions without Hanger ($W \times H \times D$)	442 mm × 133 mm × 520 mm
	Dimensions with Hanger ($W \times H \times D$)	483 mm × 133 mm × 559 mm
	Unit Net Weight	44 kg
	Rack Enclosure Standard	Standard 19-inch 3U rack form factor
	Ingress Protection Rating	IP20
Operating Conditions	Charge Temperature Range	0°C to +55°C
	Discharge Temperature Range	-20°C to +55°C
	Storage Temperature Range	-20°C to +45°C
	Maximum Operating Altitude	4,000 m (13,123 ft)
	Cooling Mechanism	Natural convection (passive fanless)
BMS & Compliance	Communication Protocols	CAN
	Autonomous Recovery	Auto-reboot after undervoltage cutoff
	Firmware Maintenance	Remote diagnosis and updates via GoodWe hybrid inverter
	Safety Certifications	IEC 62619, IEC 63056, UN38.3, ADR, CE
	Grid Applications	On-Grid, On-Grid + Backup, Pure Off-Grid
