Core System Performance

Output Capabilities: Delivers a continuous 6000W (6kW) single-phase pure sine wave AC output to power sensitive household appliances safely.
Peak Surge Power: Can briefly double its output capacity to handle motor and compressor startup loads, offering a max output apparent power of 12,000 VA for up to 5 seconds.
Conversion Efficiency: Reaches a peak maximum efficiency of 98.6% with an MPPT operational efficiency of 99.9%, minimizing energy loss during conversion.

Solar & MPPT Specifications

Massive PV Oversizing: Designed with a 200% PV oversizing ratio, accepting a maximum solar panel input power of up to 12,000W (12kW).
Dual MPPT Architecture: Features 2 independent MPP Trackers to manage separate solar panel orientations or partial shading.
Voltage & Current Thresholds: Operates on a wide MPPT tracking range of 50V – 480V (with a max DC input voltage of 530V) and handles up to 21A of maximum current per MPPT input.

Low-Voltage Storage: Built for low-voltage setups, operating within a nominal battery voltage of 48V (actual working range of 40V to 60V).
Chemistry Compatibility: Fully supports both Lithium-ion (LiFePO4) and traditional Lead-acid battery storage banks.
Rapid Charge / Discharge: Boasts a maximum continuous charging and discharging current of 130A, accelerating battery replenishment during short grid-recovery windows.

Weatherproof Enclosure: Rated at an IP66 ingress protection level alongside aviation-grade connectors, making it fully dust-tight and protected against heavy seas or powerful water jets.
Temperature Resilience: Engineered to function reliably in extreme climates, with an operational temperature window stretching from -35°C up to +60°C.
Dimensions & Form Factor: Compact wall-mounted layout measuring 337 × 456 × 201 mm and weighing under 13 kg, significantly reducing structural footprint.

Local User Interface: Features a built-in 4.3-inch LCD touchscreen for standalone programming and performance tracking.
Remote Monitoring Protocols: Integrates Wi-Fi, Bluetooth, and RS485 hardware channels.
Smart Interfacing: Equipped with integrated dry contacts to automatically actuate external emergency diesel generators or manage smart load dumping.
